NDB1L-32 Series RCCB, Nader

Rated Voltage (Ue)

AC230/240

Rated Current (In)

6A, 10A, 16A, 20A, 25A, 32A

Tripping Characteristic

C：5In～10In

Tripping curve

C curve

Rated Breaking Capacity (Icn)

4.5kA, 6kA(UL1053)

Rated Ultimate Short-Circuit Breaking Capacity (Icu)

4.5kA, 6kA(UL1053)

Rated Service Short-Circuit Breaking Capacity (Ics)

4.5kA, 6kA(UL1053)

Number of Poles

1PN

Standards and Certificates

·CCC、CB、CE、TUV、UL1053

·GB 16917.1、IEC 61009-1、GB16917.22、IEC61009-2-2、UL1053

Environmental Requirements

RoHS

Rated Insulation Voltage

AC440V

Rated Impulse Withstand Voltage

4kV

Rated Frequency

50/60Hz

Wiring

·Adopt tunnel type wiring Version

·Connection capability: 1mm² to 10 mm²

·Connection screw M4, Torque: 1.2N.m

Mechanical Life

10000 times

Electrical Life

6000 times

Working Condition

·Ambient temperature: －25℃~＋55℃

·Storage temperature: －30℃~+70℃

·Relative air humidity ≤95%

·Altitude ≤2000m

·Pollution degree: 2

·Protection Degree: IP20
