Rated current In (A): 200A, 400A, 630A, 800A, 1000A, 1250A, 1600A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 50kA, 66kA
Rated current In (A): 630A, 800A, 1000A, 1250A, 1600A, 2000A, 2500A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690/800/1000/1140/1380/1500V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 50kA, 55kA, 60kA, 66kA, 85kA
Rated current In (A): 800A, 1000A, 1250A, 1600A, 2000A, 2500A, 3200A, 3600A, 4000A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690/800/1000/1140/1380/1500V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 60kA, 75kA, 85kA, 100kA
Rated current In (A): 4000A, 5000A, 6300A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690/800/1000/1140/1380/1500V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 66kA, 80kA, 85kA, 100kA, 120kA, 135kA
Rated current In (A): 4000A, 5000A, 6300A, 7500A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 100kA, 120kA, 150kA, 160kA
Rated current In (A): 200A, 400A, 630A, 800A, 1000A, 1250A, 1600A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 42kA, 65kA
Tripping characteristic curve Tripping characteristic curve Outline and installation dimension
Rated current In (A): 2000A, 2500A, 2900A, 3200A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 80kA, 100kA
Rated current In (A): 800A, 1000A, 1250A, 1600A, 2000A, 2500A, 3200A, 3600A, 4000A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690/800/1000/1140V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 55kA, 70kA, 75kA, 100kA
Rated current In (A): 4000A, 5000A, 6300A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690/800/1000/1140V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 60kA, 75kA, 85kA, 120kA
Rated current In (A): 200A, 400A, 630A, 800A, 1000A, 1250A, 1600A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 42kA, 65kA
Rated current In (A): 400A, 630A, 800A, 1000A, 1250A, 1600A, 2000A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 65kA, 80kA
Rated current In (A): 2000A, 2500A, 2900A, 3200A. Rated operational voltage Ue (V): AC400/415/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 75kA, 100kA
Rated current In (A): 2000A, 2500 3200A, 3600A, 4000A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/400/480/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 80kA, 100kA
Rated current In (A): 4000A, 5000A, 6300A. Rated operational voltage Ue (V): AC220/230/240/380/400/415/440/480/660/690V. Poles: 3P, 4P. Rated limit short-circuit breaking capacity Icu: 85kA, 120kA
Rated current In (A): 1000A, 1250A, 1600A, 2000A. Rated operational voltage Ue (V): AC254/508/635/730V. Poles: 3P. Rated limit short-circuit breaking capacity Icu: 65kA, 75kA
